Fiberglass Cloth Aluminum Foil Tape Contact
Fiberglass Cloth Aluminum Foil Tape
Fiberglass cloth aluminum foil tape is a composite tape constructed with a fiberglass cloth substrate laminated with aluminum foil on one or both sides. It is coated with high-performance pressure-sensitive adhesive (PSA) and lined with release paper or film.
Product Details Features
High-Temperature Resistance: Suitable for long-term use in a temperature range of -30°C to 200°C.
Enhanced Flame Retardancy: When combined with flame-retardant adhesives, it provides superior fire resistance compared to standard aluminum foil tapes.
Mechanical Strength: The fiberglass reinforcement offers exceptional tensile strength and tear resistance.
Primary Applications
Thermal Insulation Wrapping: For high-temperature equipment such as boilers, steam pipelines, and hot air ducts to reflect heat and reduce energy loss.
Fireproof Sealing: Sealing firewall gaps, ventilation duct joints, and cable penetration holes. Fire protection in high-temperature zones or cable channels in ships/high-speed rail cabins.
EMI Shielding: Used in server cabinets, communication base stations, and medical equipment to block electromagnetic interference.
Corrosion Resistance & Sealing: Provides resistance to acids/alkalis and seals/protects surfaces in corrosive environments.
Technical Parameters
Aluminum thickness (μm) | Fiberglass fabric areal weight(g/㎡) | Adhesive Type | Liner | Size (W/D) (mm×m) | Tensile strength (N/cm) | Initial Tack | Holding Power (h) | Tensile Strength (N/cm) |
6 | 75 | Flame retardant | Kraft paper | 120×100 | ≥6 | ≥ 10 # | ≥ 24 | ≥ 100 |
8 | 100 | Solvent-based | White paper | 50×50 | ≥6 | ≥ 10 # | ≥ 24 | ≥ 100 |
8 | 120 | Water-based | White paper | 75×50 | ≥4 | ≥ 10 # | ≥ 24 | ≥ 100 |
16 | 120 | Solvent-based | PET | 1200×1000 | ≥6 | ≥ 10 # | ≥ 24 | ≥ 100 |
16 | 210 | Solvent-based | Glassine paper | 1050×50 | ≥6 | ≥ 10 # | ≥ 24 | ≥ 100 |
Storage Conditions
Store in a cool, dry environment at room temperature (Temperature: -5°C to 40°C, Relative Humidity: <80% RH). Avoid direct sunlight and exposure to heat sources.
Shelf Life
Water-based & Flame-Retardant Adhesives: 6 months
Solvent-based : 12 months
Related Applications
Tolerance range
Aluminum Foil Thickness: ±0.005mm,
Total Thickness: ±0.01mm,
Width: ±0.5mm,
Length: ±0.2m
